CPU
|
Intel® Socket 775 Core™2 Quad/Core™2 Extreme/Core™2 Duo/Pentium® dual-core/Celeron® dual-core /Celeron® Processors
|
|
|
Compatible with Intel® 05B/05A/06 processors
|
|
|
Support Intel® 45nm Multi-Core CPU
|
|
|
*Refer to www.asus.com for Intel CPU support list
|
|
Chipset
|
Intel® G41 /ICH7
|
|
Front Side Bus
|
1333/1066/800 MHz
|
|
Memory
|
2 x240-pin DIMM, Max. 8 GB, DDR3 1333(O.C.)/1066/800 Non-ECC,Un-buffered Memory
|
|
|
Dual Channel memory architecture
|
|
|
** Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List)
|
|
|
*** When installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.
|
|
Expansion Slots
|
1 x PCIe x16
|
|
|
1 x PCIe x1
|
|
|
2 x PCI
|
|
VGA
|
Integrated Intel GMA X4500 graphics
|
|
|
Maximum shared memory of 1G
|
|
|
Supports RGB with max. resolution 2048 x 1536 (@75Hz)
|
|
|
Supports Microsoft® DirectX® 10
|
|
Storage
|
Southbridge
|
|
|
1 xUltraDMA 100/66/33
|
|
|
4 xSATA 3 Gb/s ports
|
|
LAN
|
PCIe Gb LAN
|
|
Audio
|
ALC887 8-Channel AUDIO CODEC
|
|
|
*Choose the chassis with HD audio module in front panel to support 8-Channel audio output
|
|
|
Supports Jack-detect and Multi-Streaming teconologies
|
|
|
Supports S/PDIF out interface
|
|
USB
|
8 USB 2.0/1.1 ports (4 ports at mid-board, 4 ports at back panel)
|
|
ASUS Unique Features
|
ASUS MyLogo 2
|
|
|
ASUS EZ Flash 2
|
|
|
ASUS CrashFree BIOS 3
|
|
|
ASUS Q-Fan
|
|
|
ASUS Anti-Surge
|
|
|
ASUS EPU-L
|
|
|
ASUS Express Gate
|
|
|
Turbo Key
|
|
|
AI NET2
|
|
Overclocking Features
|
SFS (Stepless Frequency Selection)
|
|
|
- FSB tuning from 200MHz to 800MHz at 1MHz increment
|
|
|
Overclocking Protection
|
|
|
- ASUS C.P.R.(CPU Parameter Recall)
|
